NEXT-GENERATION BOBCAT™ 265
It has all the dependability that made the Bobcat machine a legend, plus more capabilities to take on more jobs — and a faster, easier setup too.
MORE CAPABILITIES
It can take on more jobs while delivering the uncompromised performance you need.
DIGITAL INTERFACE
Speeds setup and makes it less complicated.
SMOOTH, STABLE ARCS
Delivers uncompromised stick arc performance with 7018 and 6010 electrodes.
AUTO-SET™ TECHNOLOGY
Makes weld parameter setup fast, easy and accurate for operators of all skill levels.
FULL AUXILIARY POWER
Ensures that you’ll always have the auxiliary power you need for job site tools at any weld setting.
NO POWER SPIKES
Jobsite tools can run without interruption, helping you get more done.
LIGHTER AND SMALLER
Over 100 pounds (45 Kg) lighter and 13% smaller than previous models, it’s easier to move and takes up less space on trucks.
MORE DATA VISIBILITY
- Predictive maintenance information helps you plan necessary service time.
- Productivity screens make it easier for you to monitor machine use.
REMOTE START/STOP
Easily shut off the engine to reduce idling time — get lower fuel costs and less job site noise.
OPTIONAL BATTERY CHARGE/CRANK ASSIST
Ensures that you have reliable DC output when you need it, without carrying a separate charger.
OPTIONAL ARCREACH™ TECHNOLOGY
Make parameter changes at the weld joint, eliminating walks to the machine. Increase arc-on time, improve your bottom line and ensure a safer job site.
MAKE YOUR WORK LEGENDARY WITH THE NEXT-GENERATION
BOBCAT™ 265
Spec Sheet
Processes
Air Carbon Arc Cutting and Gouging (CAC-A)
Flux Cored (FCAW)
MIG (GMAW)
Stick (SMAW)
TIG DC (GTAW-DC)
General Specifications
| Title |
Bobcat™ 265 (Kohler), With Remote Start/Stop |
| Industries Interests |
Heavy Equipment
Construction and Fabrication |
| Amperage |
20 A - 265 A |
| Weldable Metals |
Aluminum
Stainless Steel
Steel |
| Rated Carbon Diameter |
3/16 in (4.8 mm) |
| Current Type |
DC |
| Portability |
Lift Eye (Standard)
Running Gear / Cart (Optional)
Trailer (Optional) |
| Engine Brand |
Kohler |
| Engine Idle Speed |
2400 RPM |
| Engine Weld Speed |
3600 |
| Fuel Tank Size |
11 Gallon (41.6 Litres) |
| Fuel Type |
Gasoline |
| Horsepower |
23.5 hp |
| Weld Output |
CC / CV |
| Rated Output |
CC/DC Stick/TIG 265 A at 27 V, 100% duty cycle, CV/DC MIG/FCAW 265 A at 27 V, 100% duty cycle |
| Single Phase Auxiliary Continuous Power |
9500 W |
| Single Phase Auxiliary Peak Power |
11000 W |
| Sound Rating |
64 dB @ idle and 73 dB @ weld |
| Applications |
Aluminum Welding
Fabrication
Field Welding
Industrial Welding
Mobile Fabrication & MRO
Outdoor
Stainless Steel
Structural Welding |
| Net Width |
20.13 in (51cm) |
| Net Height |
26.5 in (67cm) |
| Net Length |
37.06 in (94cm) |
| Net Weight |
382 lbs (173Kg) |
| Warranty |
3 Years |
